Engineering and remote access
7.6 Cyclic and acyclic data
Power supply system SITOP PSU8600
Manual, 09.2018, A5E36758446-5-76
237
Operating states SITOP UPS8600
Operating state of the UPS module
UPS module is in the "Off" operating state.
UPS module is presently booting.
2 = Default Complete buffer readiness: The energy storage device of the UPS module is fully
charged (normal operation).
3 = Buffering UPS module is in the buffer mode: The power supply system is supplied via the UPS
4 = ErrorOff Shutdown after error: An error occurred when operating the UPS module. The UPS
module is not operational and must be restarted by switching off the supply voltage and
After a shutdown due to a fault, the UPS module can be restarted.
The UPS module is deactivated.
Performing firmware update.
Battery test is being carried out
Operating states of the SITOP BAT8600
Operating state of the battery module*
Battery module is in the "Off" operating state.
Battery module is presently running up.
2 = Default Complete buffer readiness: The energy storage device of the UPS module is fully
charged (normal operation).
Battery module run down after fault.
Battery charging is restricted.
End of lifecycle has been reached.
6 = MaintenaceRequired Maintenance required.
Battery module successfully replaced.
9 = Not ready for buffering
Battery module is not fully charged and is not ready for buffering.
10 = Not completely loaded but
Battery module is not fully charged, but is ready for buffering.
12 = DeepDischargeRecovery
Battery module was deep-discharged and is in the recovery phase.
*) Is also applicable for battery modules from third-party manufacturers.
