Operator control at the device
3.1 Setting the output voltage and response threshold value of the output current
Power supply system SITOP PSU8600
82 Manual, 09.2018, A5E36758446-5-76
Setting the output voltage and response threshold value of the
output current
The potentiometer of the output is used to set the output voltage and response threshold
value of the output current.
Note
In the REMOTE operating mode, changes made to the settings of the potentiometer for
output voltage and response threshold value of the output current have no effect. See
Chapter "
MANUAL and REMOTE operating modes (Page 88)".
Note
6EP4436-8XB00-0DY0 expansion module
In the MANUAL mode, the values set by the voltage and current potentiometers are valid fo
Voltage potentiometer for the output
Current potentiometer for the output
