Engineering and remote access
7.7 Web server
Power supply system SITOP PSU8600
282 Manual, 09.2018, A5E36758446-5-76
The following data can be seen for every output available in the system:
PSU8600 / CNX8600
Output [n]
Output voltage [V]
The procedure to use the online functions of the web server is described below.
Note
With the exception of the firmware update function, all online functions for the existing
PROFINET connection are inhibi
ted.
Using the "Output ON/OFF" function you can switch on the outputs again after an automatic
shutdown. Outputs that were switched off manually or using the remote configuration are not
switched on using the "Output ON/OFF" function.
