7.5 SIMATIC STEP 7
Power supply system SITOP PSU8600
Manual, 09.2018, A5E36758446-5-76
213
Parameters of the UPS module
For the parameterization of the UPS modules, under the "Properties" tab for the basic unit,
select subgroup "Buffering".
You select UPS module parameters in subgroup "UPS8600 > Module parameters".
UPS8600 General
Select between "High" and "Low".
Select at which time intervals the battery test should be performed.
Shows whether the buffer timer is activated
Enter a maximum buffer time.
Battery modules do not have to be configured.
Parameterizing the basic unit
The procedure is the same for all parameters. This Chapter describes the general procedure
to reach the configuration dialog. The individual parameters and their possible values are
described in the following subsections.
● The SITOP PSU8600 has been integrated in the opened project and networked.
1. Open network view "NetPro" ("Options > Configure Network").
The IO controller and the networked SITOP PSU8600 are displayed.
2. In the network view, double-click on the SITOP PSU8600.
3. Open the hardware configuration.
4. In the hardware configuration, double-click on the entry of a SITOP PSU8600 in the
station window (slot 0.1).
5. In the configuration dialog, click on the "Parameter" tab.
6. Click on the required subgroup.
The subgroup opens.
7. Enter the values.
8. Confirm your entry by clicking on "OK".
The parameters are stored in the project.
