Engineering and remote access
7.6 Cyclic and acyclic data
Power supply system SITOP PSU8600
242 Manual, 09.2018, A5E36758446-5-76
Reading and writing data sets SITOP BAT8600
Index
Slot
Subslot
Data set
Description
Data size
6 1-6 2-6 Device information Reading Information about the SITOP BAT8600
battery modules.
42 bytes
32 1-6 2-6 Actual state infor-
mation
Reading Status information about the
battery modules SITOP BAT8600.
10 bytes
Reading and writing data sets for third-party battery modules
Index
Slot
Subslot
Data set
Description
Data size
1 1-6 2 General values
Reading
General settings
16 bytes
Writing Adjustable parameters for the general
configuration
16 bytes
32 1-6 2 Actual state infor-
mation
Reading Status information about the battery mod-
ules
4 bytes
7.6.2.2
Data sets SITOP PSU8600
Index 1: General remote values (reading/writing)
Data
Description
Data type
Priority buffered
Channel 1 (0/255)
Prioritized buffering of output 1 When the power fails, output 1 of the basic unit
can be prioritized to increase the available buffer time. In order that the remain-
ing buffer energy is only used for output 1, in the buffer mode, all of the addi-
tional outputs of the power supply system are switched off after half of the
nominal buffer time that is available. When the line supply is available, the
outputs that have been switched off are automatically switched-on again.
Unsigned8
Startup mode System start charac-
teristics Defines the
time delay when
switching on the out-
puts after the device
has powered up. For a
defined switch-on
delay time, the outputs
are switched on in a
fixed sequence 1,
2,…n with an identical
delay time between
the outputs. For a
variable switch-on
delay, each output
uses an individually
specified delay time
based on a common
starting point.
0 = StartupDelayOff
No on delay
Unsigned8
1 = StartupDelay25ms On delay 25 ms Outputs
are switched on in an
ascending sequence
(starting with output 1 of
the basic unit) in intervals
of 25 ms.
2 = StartupDelay100ms On delay 100 ms Outputs
are switched on in an
ascending sequence
(starting with output 1 of
the basic unit) in intervals
of 100 ms.
3 = StartupDelay
LoadOptimized
Load-optimized on delay:
Outputs are switched on
in an ascending sequence
(starting with output 1 of
the basic unit) in a load-
optimized fashion.
