Siemens SITOP PSU8600 User Manual

Engineering and remote access
7.6 Cyclic and acyclic data
Power supply system SITOP PSU8600
268 Manual, 09.2018, A5E36758446-5-76
Data
Description
Data type
5 = EndOfLife-
timeReached
End of lifecycle has been
reached.
6 = MaintenaceRe-
quired
Maintenance required.
7 = Change completed Battery module success-
fully replaced.
8 = Battery defective
Battery module defective
9 = Not ready for buff-
ering
Battery module is not fully
charged and is not ready
for buffering.
10 = Not completely
loaded but ready for
buffering
Battery module is not fully
charged, but is ready for
buffering.
11 = Ready for buffer-
ing
Ready for buffering.
12 = DeepDischarge-
Recovery
Battery module was deep-
discharged and is in the
recovery phase.
Operating Hours [h]
Total operating hours
Unsigned32
Battery temperature
[°C]
Temperature of the battery module Signed8
Fill byte(s) - Unsigned8
7.6.2.7
Data sets for third-party battery modules
Index 1: General (reading/writing)
Data
Description
Data type
Type Battery type
0
Pb
Unsigned8
1 pPb
Operating Temperature [°C]
Operating temperature
Signed8
Capacity [Wh] Combined nominal capacity of the connected bat-
tery modules
Unsigned16
EndOfChargeVoltage [10mV]
Final charge voltage
Unsigned16
MaxChargeCurrent [10mA]
Maximum charging current
Unsigned16
TempCoefficient
Temperature coefficient
Unsigned16
StartOfPreserveVoltage [10mV]
Start of the trickle charging voltage
Unsigned16
EndOfDischargeVoltage [10mV]
End of the discharge voltage
Unsigned16
