7.6 Cyclic and acyclic data
Power supply system SITOP PSU8600
230 Manual, 09.2018, A5E36758446-5-76
7.6.1.2
Output data
In the following tables you can find an overview of the output data, which is cyclically sent
from the PROFINET IO-Controller to the SITOP PSU8600 and the expansion modules.
Output data SITOP PSU8600
Slot
Subslot
Data
Description
Value range
Data size
0 2 Device Reset_In Status of input "Reset_In": This
input resets all active faults and
reactivates all of the outputs that
are in the "Ready for restart" ope-
rating state.
0 = false, >0 = true
(default setting: false)
Unsigned8
Device Ithreshold
[1 %]
Prewarning threshold total current
of the SITOP PSU8600.
0 - 100 %
(default setting: 90 %)
Unsigned8
System overload alarm
threshold time [ms]
Time delay before an alarm is
issued after a system overload was
detected.
0 - 60 000 ms
(default setting:
5 000 ms)
Unsigned16
Main power outage
alarm threshold time
[ms]
Time delay before an alarm is
issued after failure of the power
supply voltage (power supply
changes into the buffer mode).
0 - 1 000 ms
(default setting: 0 ms)
Unsigned16
Buffering disable Buffer module was deactivated via
control command.
0 = false, >0 = true
(default setting: false)
Unsigned8
Data block active Indicator: Data block contains valid
data.
0 = false, >0 = true
(default setting: false)
Unsigned8
0 3 Output Utarget
[10 mV]
Currently set setpoint of the output
voltage.
4.0 V - 28.0 V
(default setting:
24.0 V)
Unsigned16
Output Ilimit [10 mA] Response threshold value of the
output current for the particular
output. When this is exceeded, the
output current is interpreted as
having an overload condition and is
shut down with a time delay - or
limited.
Output 20 A: 0.0 A -
20.0 A
(default setting:
20.0 A)
Output 40 A: 0.0 A -
40 A
(default setting: 40 A)
Unsigned16
Output Ithreshold Prewarning threshold of the config-
ured response threshold for the
output current in %. An alarm is
initiated when the actual output
current exceeds this value. Opera-
tion is continued without any re-
strictions. Prewarning is
deactivated by entering "0 %".
0 - 100 %
(default setting: 90 %)
Unsigned8
Channel1 Output
Enable
Switches the output on or off. A
possible automatic shutdown due
to overload or power failure is not
taken into account.
0 = false, >0 = true
(default setting: false)
Unsigned8
Channel1 Reset_In Resets an overload shutdown for
this output
0 = false, >0 = true
(default setting: false)
Unsigned8
Data block active Indicator: Data block contains valid
data.
0 = false, >0 = true
(default setting: false)
Unsigned8
