Engineering and remote access
7.4 SIMATIC STEP 7 in the TIA Portal
Power supply system SITOP PSU8600
Manual, 09.2018, A5E36758446-5-76
171
SIMATIC STEP 7 in the TIA Portal
The SITOP PSU8600 power supply system can be used with SIMATIC STEP 7 in the
TIA Portal from version 14.
In SIMATIC STEP 7 in the TIA Portal, the SITOP PSU8600 basic unit and the
SITOP CNX8600, SITOP BUF8600 and SITOP UPS8600 supplementary modules can be
integrated, parameterized and diagnosed in the projects.
Note
If you wish to use SIMATIC
STEP 7 V14 in the TIA Portal, then you must install the
appropriate Hardware Support Package (HSP), in order to be able to use the
SITOP
PSU8600 and the supplementary modules with firmware V1.4. This step is not
STEP 7 V15.1.
Additional information is provided in Chapter "
Installing the Hardware Support Package
(Page 171)".
Installing the Hardware Support Package (HSP)
Note
SIMATIC STEP 7 V14
The following step
is only relevant for SIMATIC STEP 7 V14 in the TIA Portal.
You can obtain the HSP at our SITOP
-homepage (http://www.siemens.com/sitop) or directly
https://support.industry.siemens.com/cs/ww/de/view/72341852/en?dl=en).
To install the HSP, proceed as follows:
1. Start SIMATIC STEP 7 V14 in the TIA Portal.
2. Click in the project view in the "Options" menu on "Support Packages"
Dialog "Detailed information" opens. All support packages from the directory that you
specified as storage location for support packages in the settings are listed in a table.
