Engineering and remote access
7.4 SIMATIC STEP 7 in the TIA Portal
Power supply system SITOP PSU8600
Manual, 09.2018, A5E36758446-5-76
181
7.4.5
Parameter assignment
7.4.5.1
Parameters of the basic units and the supplementary modules
You can find the adjustable parameters of SITOP PSU8600 and the supplementary modules
being used in SIMATIC STEP 7 in the TIA Portal in the Inspector window under Properties
once you have selected the appropriate device.
Parameters of the basic unit
For parameterization, in the navigation area, the following settings are relevant:
Navigation area
Description
Profinet
security
Profinet
security
DCP write protection activated
Navigation area
Description
Device con-
figuration
General Make the following settings:
• Define the prioritization for output 1 for buffering when the po-
wer fails.
• Define which output characteristic should be used.
• Define a threshold value for system output current prewarning.
If this threshold is continually exceeded for a time longer than
the configured dead time for system output current prewarning,
then an alarm is output.
• Define a dead time for system output current prewarning.
• Define a general prewarning threshold for individual output
current in MANUAL mode.
• Define a dead time for alarm message 'Input voltage outside
permitted range'.
Output 1 Make the following settings for the output:
• Switch-on and switch-off output.
• Setpoint output voltage
• Response threshold value of the output current
• Define a threshold to issue an alarm.
An alarm is output if this threshold is continually exceeded for
5 ms.
• Define the on delay.
• Define the operating mode: ELECTRONIC SHUTDOWN or
CONSTANT CURRENT
