Technical data
9.7 Mechanical system
Power supply system SITOP PSU8600
398 Manual, 09.2018, A5E36758446-5-76
9.7
Mechanical system
Basic units
Basic unit
6EP3436-8SB00-2AY0
Basic unit
6EP3437-8SB00-2AY0
Connection system
Plug-in terminals with screw connection
Connections: Line input L1, L2, L3, PE: 1 screw terminal each
for 0.08 - 4 mm² solid/finely stranded
L1, L2, L3, PE: 1 screw terminal each
for 0.08 - 4 mm² solid/finely stranded
Connections: Output 2 screw terminals for 0.08 - 4 mm
2
0V: 3 screw terminals for
0.08 mm - 4 mm
2
2 screw terminals for 0.5 - 10 mm
2
0V: 3 screw terminals for
0.5 mm - 10 mm
2
Connections: Signaling contacts 11, 12, 14 (signal): 1 screw terminal
each for 0.2 - 1.5 mm²
11, 12, 14 (signal): 1 screw terminal
each for 0.2 - 1.5 mm²
Connections: Auxiliary contacts RST (reset): Plug-in terminal (common
with the signal) with 1 screw connection
for 0.2 - 1.5 mm²
RST (reset): Plug-in terminal (common
with the signal) with 1 screw connection
for 0.2 - 1.5 mm²
Connections: Interface Ethernet /
PROFINET
Two RJ45 sockets (2 port switch) Two RJ45 sockets (2 port switch)
Width of the housing
80 mm
125 mm
Height of the housing
125 mm
125 mm
Depth of the housing
150 mm
150 mm
Mounting width
80 mm
125 mm
Mounting height
225 mm
225 mm
Weight, approx.
1.8 kg
2.65 kg
Product feature of the housing: Hous-
ing that can be lined up next to one
another
Yes Yes
Type of mounting: Wall/panel mounting
No
No
Type of mounting: Rail mounting
Yes
Yes
Mounting Can be snapped onto standard
EN 60715 35x15 mounting rails
Can be snapped onto standard
EN 60715 35x15 mounting rails
