Engineering and remote access
7.4 SIMATIC STEP 7 in the TIA Portal
Power supply system SITOP PSU8600
Manual, 09.2018, A5E36758446-5-76
193
Parameterizing a UPS module
Parameters of the UPS module
For the parameterization of the UPS modules, under the "Properties" tab for the basic unit,
select subgroup "Buffering".
You select UPS module parameters in subgroup "UPS8600 > Module parameters".
UPS8600 General
Select between "High" and "Low".
Select at which time intervals the battery test should be performed.
Shows whether the buffer timer is activated
Enter a maximum buffer time.
Battery modules do not have to be configured.
Loading the configuration (commissioning)
In the delivered state, the SITOP PSU8600 has not yet been assigned any IP address and
the DHCP protocol is deactivated.
If the SITOP PSU8600 is connected to an IO controller (SIMATIC S7 control) for the first
time, then it must be assigned a device name and an IP address by the IO controller. A new
configuration can be loaded to the device using SIMATIC STEP 7 in the TIA Portal.
● The SITOP PSU8600 has been correctly connected and linked with the network.
● PG/PC (Siemens programming device) with SIMATIC STEP 7 in the TIA Portal is
connected with the network.
Identifying a SITOP PSU8600 in the network
From SIMATIC STEP 7 in the TIA Portal you can get LED "SF" at the SITOP PSU8600 to
flash, which means that you can uniquely identify it as module in a network.
1. From the toolbar, open the "Online > Accessible nodes" menu.
2. Select "PN/IE" as the PG/PC interface type.
3. Select the PG/PC interface that is connected to the network.
4. Select the connection with the Subnet, in which the SITOP PSU8600 is located.
All of the available SITOP PSU8600 devices in the selected subnet are displayed.
