Engineering and remote access
7.6 Cyclic and acyclic data
Power supply system SITOP PSU8600
Manual, 09.2018, A5E36758446-5-76
267
Data
Description
Data type
LED state Actual display status of
the LEDs. Each LED is
represented by 2 bits:
• Bit0/1: OK
• Bit2/3: BAT.
• Bit4/5: Battery 1:
• Bit 6/7: Battery 2:
• Bit 8/9: Battery 3:
• Bit 10/11: Battery 4:
• Bit 12/13: Battery 5:
• Bits 14-15: Not used
0
LED is off.
Unsigned16
1 LED lights up.
2
LED flashes at 1 Hz.
3 LED flashes at 2 Hz
7.6.2.6
Data sets SITOP BAT8600
Index 6: Device information (reading)
Data
Description
Data type
Order number Article No./Order number VisibleString(20)
Product state
Product release
Unsigned8
Fill byte(s)
-
Unsigned8
Software version
Software version
Unsigned32
Serial number
Serial number
VisibleString(16)
Index 32: State information (reading)
Data
Description
Data type
Capacity of the battery
[Wh]
Charge capacitance of the battery module Unsigned16
State of health [%]
Result of the last battery test "state of health" (SoH)
Byte
Module operation state Operating state 0 = Off Battery module is in the
"Off" operating state.
Unsigned8
1 = Boot Battery module is pres-
ently running up.
2 = Default Complete buffer readi-
ness: The energy storage
device of the UPS module
is fully charged (normal
operation).
3 = Error Off Battery module run down
after fault.
4 = ChargingRestrict-
ed
Battery charging is re-
stricted.
