Mounting and maintenance
4.6 System response for a modified hardware configuration
Power supply system SITOP PSU8600
134 Manual, 09.2018, A5E36758446-5-76
Response after removing an individual component
Incorrect response and damage after switching on again
Different settings and incorrect wiring, that can be caused by changes made to the system
configuration, can result in an incorrect response and subsequent damage.
After making any change to the system configuration, ensure the correct settings of the
remaining components as well as the correctness of the associated wiring to avoid any
incorrect response and damage after switching on again.
Note
By removing modules, it is possible that the previous module position of the remaining
modules is changed. This can result in modules,
whose position has changed, being
deactivated and outputs shut down.
Response after removing a component and powering up in the MANUAL mode
● Buffer modules and UPS modules are automatically commissioned.
● Expansion modules with an unchanged module position are activated with the last
operating state of the outputs before shutdown.
● For expansion modules with changed module position, after switching on again, the
outputs are in the operating state "manually shut down" (the LEDs of the outputs are lit
yellow).
The outputs are switched-on by pressing their associated buttons.
Response after removing a component and powering up in the REMOTE mode
● Buffer modules and UPS modules with unchanged module position are automatically
commissioned.
● Expansion modules with an unchanged module position are activated with the last
operating state of the outputs before shutdown.
● For modules with changed module position, the system response depends on the specific
case.
