Technical data
9.2 Output data
Power supply system SITOP PSU8600
Manual, 09.2018, A5E36758446-5-76
385
9.2
Output data
Basic units
Basic unit
6EP3436-8SB00-2AY0
Basic unit
6EP3437-8SB00-2AY0
Output
Regulated, isolated DC voltage
Number of outputs
1
1)
1
1)
Rated output voltage U
out rated
DC
(factory setting)
24 V 24 V
Total tolerance, static ±
3 %
3 %
Static line regulation, approx.
0.2 %
0.2 %
Static load regulation, approx.
0.1 %
0.1 %
Residual ripple in the load range
peak-peak, max.
100 mV 100 mV
Spikes peak-peak, max.
(bandwidth, approx. 20 MHz)
200 mV 200 mV
Adjustment range
• Comment
4 - 28 V
Derating > 24 V: 4 % I
out
/V
4 - 28 V
Derating > 24 V: 4 % I
out
/V
Output voltage adjustment Via potentiometer
or in the REMOTE operating mode
Via potentiometer
or in the REMOTE operating mode
Operating display 3-color LED for the device operating
status;
LED for MANUAL / REMOTE mode;
4 LEDs for PROFINET communication;
3-color LED for the device operating
status;
3-color LED for the device operating
status;
LED for MANUAL / REMOTE mode;
4 LEDs for PROFINET communication;
3-color LED for the device operating
status;
Signaling Relay contact (changeover contact,
rating 60 V DC /0.3 A) for "O.K."
Relay contact (changeover contact,
rating 60 V DC /0.3 A) for "O.K."
Switch-on/switch-off behavior No overshoot of U
out
(Soft-Start)
Starting delay, max. 1 s 1 s
Rise time of the output voltage, max.
500 ms
500 ms
Switching on outputs In conjunction with CNX8600 expansion module: all outputs are simultaneously
switched-on after the device powers up, after a delay time of 25 ms, 100 ms – or
"load optimized" where the outputs are sequentially switched-on, can be selected
via DIP switch
Rated output current I
out rated
20 A
40 A
Current range 0 - 20 A
50 ... 60 °C:
Derating 2.5 %/K
0 - 40 A
50 … 60 °C:
Derating 2.5 %/K
