Siemens SITOP PSU8600 User Manual

Power supply system SITOP PSU8600
Manual, 09.2018, A5E36758446-5-76
383
Technical data
9
Note
Technical data apply for a rated input voltage, rated load and 25
°C ambient temperature if
nothing else is specif
ied.
9.1
Input data
Basic unit
6EP3436-8SB00-2AY0
Basic unit
6EP3437-8SB00-2AY0
Input
3-phase AC
3-phase AC
Rated voltage U
in rated
400 - 500 V
400 - 500 V
Voltage range
320 - 575 V
320 - 575 V
• Comment
Derating for U
in
320 - 360 V and 530 - 575 V, see "Figure 9-3 Output current
as a function of the input voltage (only basic unit SITOP PSU8600 6EP3436-
8SB00-2AY0) (Page 389)" and "Figure 9-4 Output current as a function of the
input voltage (power supply system SITOP PSU8600 6EP3436-8SB00-2AY0
with a minimum of one expansion module SITOP CNX8600) (Page 389)".
Wide-range input
Yes
Yes
Overvoltage strength
2.3 × U
in rated
, 1.3 ms
2.3 × U
in rated
, 1.3 ms
Line failure buffering at I
out rated
, min
15 ms
1.2)
15 ms
1.2)
Power-failure buffering
At U
in
= 400 V
At U
in
= 400 V
Rated line frequency
50 - 60 Hz
50 - 60 Hz
Line frequency range
47 - 63 Hz
47 - 63 Hz
Input current at rated input voltage 400 V
1.4 A
2.75 A
Input current at rated input voltage 500 V
1.1 A
2.2 A
Inrush current limiting (25 °C), max.
14 A
14 A
I²t, max.
1.2 A
2
s
2.24 A
2
s
Integrated input fuse
None
None
Protection/fusing in the line feeder cable
(IEC 898)
required: 3-pole, coupled miniature
circuit breaker 6 - 16 A characteris-
tic C or circuit breaker 3RV2011-
1DA10 (setting 3 A) or 3RV2711-
1DD10 (UL489-listed, DIVQ)
required: 3-pole, coupled miniature
circuit breaker 10 - 16 A characteris-
tic C or circuit breaker 3RV2011-
1DA10 (setting 3 A) or 3RV2711-
1DD10 (UL489-listed, DIVQ)
1)
Can be expanded by max. 2 buffer components (buffer module, UPS module)
2)
in conjunction with CNX8600 expansion module: Prioritized supply of the output when the power fails, can be selected
using DIP switch.
