Description, device design, dimension drawing
2.5 Description of the battery modules
Power supply system SITOP PSU8600
28 Manual, 09.2018, A5E36758446-5-76
2.5
Description of the battery modules
If the power supply fails, the battery modules provide their saved energy via the UPS
module. SITOP BAT8600 battery modules are connected to the SITOP UPS8600 UPS
module. Up to 5 SITOP BAT8600 battery modules can be connected to a UPS module. The
battery modules connected to a UPS module must be of the same type.
Battery module versions
2 battery module types are available: Modules with lithium iron phosphate (LiFePO4)
batteries – or with lead (Pb) batteries. Every module includes 4 maintenance-free batteries.
Table 2- 5 Battery modules for the uninterruptible power supply with the UPS8600 UPS module
Designation
Energy content
Buffer time
1)
Article number
LiFePO4 battery module 264 Wh typ. 14 min
(system power 960 W)
typ. 29 min
(system power 480 W)
6EP4143-8JB00-0XY0
Battery module Pb 380 Wh typ. 10 min
(system power 960 W)
typ. 25 min
(system power 480 W)
6EP4145-8GB00-0XY0
1)
Valid for a new, fully charged battery module at an ambient temperature of 25 °C
