Yamaha 01V96 User Manual

110 Chapter 9—Aux Outs
01V96 Version 2—Owner’s Manual
Setting Aux Out 1–8 from the Display
To set Aux Out 1–8 parameters, you can either move the cursor to the desired parameter on
the screen and change the value, or operate the desired button or control on the top panel.
This section explains how to set the parameters on the screen.
Attenuating Aux Outs
To attenuate Aux Out 1–8 signals, press the [EQ] button, then press the [F4] button to dis-
play the EQ | Out Att page.
The parameters on this page (and the procedure for setting them) are the same as for Input
Channels (see page 83).
Delaying Aux Outs
To delay Aux Out 1–8 signals, press the DISPLAY ACCESS [ /INSERT/DELAY] button
repeatedly until the /INS/DLY | Out Dly page appears.
The parameters on this page (and the procedure for setting them) are the same as for Input
Channels, except that this page does not include the MIX/FB.GAIN parameters (see
page 80).
Tip: Refer to Chapter 10 “Input & Output Patching” on page 121 for more information on
how to set inserts.
Tip: You can also display the Out Dly page if you select the desired Aux Out (1–8) by pressing
the corresponding [SEL] button while the DLY-related parameters are indicated on the page.

Yamaha 01V96 Specifications

General

Channels	40
Mic Preamps	16
Bit Depth	24-bit
MIDI	Yes
EQ Bands	4-band Parametric
Aux Sends	8
A/D-D/A Conversion	24-bit
Effects Processors	4
Power Supply	Internal
Type	Digital
Sample Rate	44.1 kHz, 48 kHz
Effects	Yes
USB	No
Weight	33 lbs
Inputs - Other	8 digital
Outputs - Digital	AES/EBU, S/PDIF
Computer Connectivity	No
Sampling Rate	44.1 kHz, 48 kHz
Internal Processing	32-bit
Dynamic Processing	Gate, Compressor, Limiter
Digital I/O	AES/EBU, S/PDIF
Analog I/O	XLR, TRS
Outputs - Main	2
