94 Chapter 7—Input Channels
01V96 Version 2—Owner’s Manual
When you switch the Pair Mode, the combinations of channel numbers displayed on the
page also change.
3 Move the cursor to the desired channel’s MONOx2 button (
2), then press
[ENTER].
The channels are paired.
4To cancel a pair, move the cursor to the desired channel’s STEREO button,
then press [ENTER].
Naming Input Channels
By default, Input Channels are named CH1, CH2, etc. You can change these names if
desired. For example, it may be helpful for mixdown if you name a particular Input Chan-
nel with the type of musical instrument connected to the corresponding input jack.
1 Press the DISPLAY ACCESS [PATCH] button repeatedly until the Patch | IN
Name page appears.
You can specify Short names in the center column (1) and Long (full) names in the right
column (
2).
When the Name Input Auto Copy check box (
3) is on, the first four characters of a
newly-entered Long name are automatically copied to the Short name. On the other hand,
a newly-entered Short name is automatically added to the beginning of the Long name.
You can reset all channel names to their default names by moving the cursor to the INI-
TIALIZE button, then pressing [ENTER].
Note:
• When Pair mode is switched, only the channel numbers change. The mix parameters of the
paired partners do not change.
•For example, if you change Pair mode from Horizontal to Vertical, the Input Channel “2”
indication changes to Input Channel “17.” However, its parameters do not change. (If Chan-
nels 1 and 2 have been paired, switching the mode will pair Channels 1 and 17.)
Tip: You can also create or cancel a pair of Output Channels in the same way on the Pair/Grup
| Output page (see page 105).
1 2
3
