286 Appendix B: Specifications
01V96 Version 2—Owner’s Manual
Analog Input Spec
In these specifications, when dB represents a specific voltage, 0 dB is referenced to 0.775 Vrms.
For 2TR IN levels, 0 dBV is referenced to 1.00 Vrms.
All input AD converters (CH INPUT 1–16) are 24-bit linear, 128-times oversampling. (@fs=44.1, 48 kHz)
+48 V DC (phantom power) is supplied to CH INPUT (1–12) XLR type connectors.
Three PHANTOM +48V switches CH1–4, 5–8, 9–12 turn on the phantom power for inputs 1–4, 5–8, 9–12 respectively.
Analog Output Specs
In these specifications, when dB represents a specific voltage, 0 dB is referenced to 0.775 Vrms.
2TR OUT [L, R] levels, 0 dBV is referenced to 1.00 Vrms.
All output DA converters are 24-bit, 128-times oversampling. (@fs=44.1, 48 kHz)
Input PAD GAIN
Actual Load
Impedance
For Use With
Nominal
Input level
Connector
Sensitivity
1
1. Sensitivity is the lowest level that will produce an output of +4 dB (1.23 V) or the nominal output level when the unit
is set to maximum gain. (All faders and level controls are maximum position.)
Nominal
Max.
before clip
INPUT A/B
1–12
0
–60 dB
3k Ω
50–600 Ω
Mics & 600 Ω
Lines
–70 dB
(0.245 mV)
–60 dB
(0.775 mV)
–40 dB
(7.75 mV)
A: XLR-3-31 type
(Balanced)
2
B: Phone jack
(TRS) (Balanced)
3
2. XLR-3-31 type connectors are balanced (1=GND, 2=HOT, 3=COLD).
3. Phone jacks are balanced (Tip=HOT, Ring=COLD, Sleeve=GND).
–16 dB
–26 dB
(38.8 mV)
–16 dB
(123 mV)
+4 dB
(1.23 V)
20
–6 dB
(338 mV)
+4 dB
(1.23 V)
+24 dB
(12.28 V)
INPUT 13–16
—
–26 dB
10k Ω 600 Ω Lines
–36 dB
(12.3 mV)
–26 dB
(38.8 mV)
–6 dB
(388 mV)
Phone jack (TRS)
(Balanced)
3
+4 dB
–6 dB
(388 mV)
+4 dB
(1.23 V)
+24 dB
(12.28 V)
CH INSERT IN
1–12
— 10k Ω 600 Ω Lines
–12 dB
(195 mV)
–2 dB
(616 mV)
+18 dB
(6.16 V)
Phone jack (TRS)
(Unbalanced)
4
4. CH INSERT IN/OUT phone jacks are unbalanced. (Tip=OUTPUT, Ring=INPUT, Sleeve=GND).
2TR IN [L, R]
— 10k Ω 600 Ω Lines
–10 dBV
(316 mV)
–10 dBV
(316 mV)
+10 dBV
(3.16 V)
RCA pin jack
(Unbalanced)
Output
Actual
Source
Impedance
For Use With
Nominal
Output level
Connector
Nominal
Max.
before clip
STEREO OUT [L, R]
150 Ω 600 Ω Lines
+4 dB
(1.23 V)
+24 dB
(12.28 V)
XLR-3-32 type (Balanced)
1
1. XLR-3-32 type connectors are balanced (1=GND, 2=HOT, 3=COLD).
OMNI OUT 1–4
150 Ω 10k Ω Lines
+4 dB
(1.23 V)
+24 dB
(12.28 V)
Phone jack (TRS) (Balanced)
2
2. Phone jacks are balanced (Tip=HOT, Ring=COLD, Sleeve=GND).
MONITOR OUT [L, R]
150 Ω 10k Ω Lines
+4 dB
(1.23 V)
+24 dB
(12.28 V)
Phone jack (TRS) (Balanced)
2
CH INSERT OUT 1–12
600 Ω 10k Ω Lines
–2 dB
(616 mV)
+18 dB
(6.16 V)
Phone jack (TRS) (Unbal-
anced)
3
3. CH INSERT IN/OUT phone jacks are unbalanced. (Tip=OUTPUT, Ring=INPUT, Sleeve=GND).
2TR OUT [L, R]
600 Ω 10k Ω Lines
–10 dBV
(316 mV)
+10 dBV
(3.16 V)
RCA Pin Jack (Unbalanced)
PHONES
100 Ω
8 Ω Phones 4 mW 25 mW
Stereo Phone Jack (TRS)
(Unbalanced)
4
4. PHONES stereo phone jack is unbalanced (Tip=LEFT, Ring=RIGHT, Sleeve=GND).
40 Ω Phones 12 mW 75 mW
