Setting the Stereo Out and Bus Out 1–8 from the Display 99
01V96 Version 2—Owner’s Manual
Bus Outs
8
Setting the Stereo Out and Bus Out 1–8 from the Display
To set the Stereo Out and Bus Out 1–8 parameters, you can either move the cursor to the
desired parameter on the display and change the value, or operate the desired button or
control on the top panel.
This section explains how to set the parameters on the display.
Attenuating the Stereo Out and Bus Out
To attenuate the Stereo Out and Bus Out signals, press the DISPLAY ACCESS [EQ] button,
then press the [F4] button to display the EQ | Out Att page. On this page, you can attenuate
the Bus Out 1–8, Aux Out 1–8, and Stereo Out signals.
The parameters on this page (and the procedure for setting them) are the same as for Input
Channels (see page 83).
Delaying the Stereo Out and Bus Outs
To delay the Stereo Out and Bus Out 1–8 signals, press the [ /INSERT/DELAY] button
repeatedly until the /INS/DLY | Out Dly page appears.
The parameters on this page (and the procedure for setting them) are the same as for Input
Channels, except that this page does not include the MIX/FB.GAIN parameters (see
page 80).
Tip: Refer to Chapter 10 “Input & Output Patching” on page 121 for more information on
how to set inserts.
Tip: You can also display the Out Dly page by pressing the [ /INSERT/DELAY] button once,
then press the [SEL] button to select the Stereo Out or Bus Out 1–8.
