Setting the Input Channels from the Display 83

01V96 Version 2—Owner’s Manual

Input Channels

E Meters

These meters indicate the levels of the post-compressor signals and the amount of gain

reduction.

F ON/OFF

The ON/OFF button turns the currently-selected Input Channel’s compressor on or off.

G PARAMETER section

These controls enable you to set the compressor parameters. (See page 273 for more

information on the parameters of each compressor type.)

Attenuating Input Channels

To set the attenuator for each Input Channel, press the DISPLAY ACCESS [EQ] button,

then press the [F3] button to display the EQ | In Att page.

Move the cursor to the knob for the desired Input Channel, then rotate the Parameter wheel

to set the amount of attenuation in the range of –96 dB to +12 dB.

Tip:

• This function is unavailable for the ST IN Channels.

•You can store the compressor settings in the compressor library, which features preset pro-

grams that can be used for various applications (see page 185).

Tip: You can also set the attenuation amount (in dB) for the currently-selected channel on

the EQ | EQ Edit page.
