238 Chapter 19—Other Functions
01V96 Version 2—Owner’s Manual
C PASSWORD
This button enables you to change the current password. Move the cursor to the PASS-
WORD button, then press [ENTER]. The Set Password window appears, enabling you
to change the password.
Enter the current password in the PASSWORD field, and a new password in the NEW
PASSWORD field. The factory default password is “1234.” Enter the new password again
in the REENTRY field located below the NEW PASSWORD field. Move the cursor to the
OK button, then press [ENTER] to change the password.
Cascading Consoles
The 01V96 features a Cascade Bus that enables cascade connection. You can connect two
01V96s in cascade using the digital inputs and outputs, or the OMNI IN and OMNI OUT
connectors. In this way, two consoles work just like one big console, integrating each unit’s
Buses 1–8, Aux Sends 1–8, Stereo Bus, and Solo Bus.
The following functions are linked between two cascaded 01V96s via the MIDI IN and
OUT ports.
•Display page selection
•Aux selection
•Solo function
•Fader Mode
•Metering Position
•Peak Hold On/Off
•Meter Fast Fall on/off
•Scene Store, Recall, and Title Edit
Tip: To clear the registered password, move the cursor to the CLEAR button, then press
[ENTER]. If you forget the password, initialize the password setting (see page 243).
Tip:
•To link functions and parameters (excluding the Solo function), turn on the Cascade
COMM Link check box on the Setup | Prefer1 page (see page 230).
• The Solo function is always linked regardless of the status of the Cascade COMM Link check
box.
• The Fader Mode will not be linked if the Master layer is selected.
