80 Chapter 7—Input Channels
01V96 Version 2—Owner’s Manual
Delaying Input Channels
To set the delay for each channel, press the [ /INSERT/DELAY] button repeatedly until
the page listed below that contains the desired channels appears.
-DLY 1-16 page
This page enables you to set the Delay function for Input Channels 1–16.
-DLY 17-32 page
This page enables you to set the Delay function for Input Channels 17–32.
The parameters on these two pages (and the procedure for setting them) are the same.
A DELAY SCALE
The following buttons determine the units of the delay value shown below the msec
value.
• meter ............................. Units are set to meters.
• feet ................................. Units are set to feet.
• sample ........................... Units are set to samples.
• beat ................................Units are set to beats.
• frame ............................. Units are set to timecode frames.
B GANG button
When this button is turned on (highlighted), the delay time for each channel in a chan-
nel pair can be set simultaneously. When this option is turned off, the delay time can be
set for each channel in a channel pair individually.
C Channel section
You can set individual delay parameters here. The delay parameters include the follow-
ing items:
• ON/OFF ........................This button switches the corresponding channel delay on or
off.
• msec............................... This parameter sets the delay time in milliseconds.
•meter/feet/sample/
beat/frame .................... The delay time can be set using units of meters, feet, samples,
beats, or frames, which you select by using the DELAY SCALE
buttons.
• MIX................................ This parameter sets the mix balance of dry (Input Channel)
and wet (delayed) signals.
• FB.GAIN .......................This parameter sets the amount of delay feedback.
2
1
3
To Next Page
