32 Chapter 3—Operating Basics
01V96 Version 2—Owner’s Manual
Selecting Channels
To select a channel on the 01V96, press the corresponding [SEL]
button. To adjust the Pan and EQ settings, use the rotary controls
in the SELECTED CHANNEL section. To select a channel on pages
that cover multiple channels, press the corresponding [SEL] but-
ton.
1 Press the corresponding LAYER button to select a layer
that includes the desired channel (see page 31).
To select ST IN channels, press the ST IN [ST IN] button.
2 Use the corresponding [SEL] button to select the desired
channel.
The channel is selected and the [SEL] button indicator lights up.
The Channel’s ID and Short name appear in the upper-left corner
of the display. If the currently-displayed page contains a relevant
channel parameter, the cursor moves to that parameter automati-
cally. If the currently-displayed page contains no such parameter, a
page that does contain such a parameter is selected automatically.
3To select the Stereo Out, press the STEREO [SEL] button.
Repeatedly pressing the STEREO [SEL] button toggles between the Stereo Out left and Ste-
reo Out right channels.
If the currently-displayed page contains a relevant Stereo Out parameter, the cursor moves
to that parameter automatically. If the currently-displayed page contains no such parame-
ter, a page that does contain such a parameter is selected automatically.
Tip: For paired Input or Output Channels, the channel for which you pressed the [SEL] button
is selected, and its indicator lights up. The [SEL] button indicator of the paired partner flashes.
EQUALIZER
HIGH
HIGH-MID
LOW-MID
LOW
Q
FREQUENCY
GAIN
SELECTED CHANNEL
PAN
