Insert Patching 127

01V96 Version 2—Owner’s Manual

Input & Output Patching

Insert Patching

The 01V96’s Input Channels and Output Channels (Stereo Out, Bus Out 1–8, Aux Out 1–8)

feature independent Insert Ins and Outs. Inputs, outputs, ADAT connector channels, slot

channels, and internal effects processor inputs and outputs can be patched to the Output

Channel Insert Ins and Outs. In this way, you can send the signals to external effects proces-

sors for processing, or insert internal effects.

Individual Insert Patching

You can patch the 01V96’s inputs, outputs, ADAT connector channels, slot channels, and

effects processor inputs and outputs to the Insert Ins and Outs. The same procedure applies

to both Input Channels and Output Channels.

1 Press the [SEL] button of an Input Channel or Output Channel for Insert

patching.

2 Press the [ /INSERT/DELAY] button repeatedly until the /INS/DLY | Insert

page appears.

This page contains the following parameters:

A POSITION

This parameter determines the insert position of the Insert patch or compressor. The

insert position is indicated by highlighted COMP or INSERT buttons.

Effects

Input Output

Output connector Input connector

Insert Out Insert In

Channel
