150 Chapter 13—Grouping Channels & Linking Parameters
01V96 Version 2—Owner’s Manual
Using Fader Groups and Mute Groups
Follow the steps below to group faders or [ON] buttons for Input Channels or Output
Channels.
1 Press the DISPLAY ACCESS [PAIR/GROUP] button repeatedly until one of the
pages that contains the desired group and channels appears.
-In Fader page
This page enables you to set Fader groups (A–H) for Input Channels 1–32 and ST IN
Channels 1–4.
-Out Fader page
This page enables you to set Fader groups (Q–T) for Bus Outs (1–8), Aux Outs (1–8)
and Stereo Out.
-In Mute page
This page enables you to set Mute groups (I–P) for Input Channels 1–32 and ST IN
Channels 1–4 respectively.
-Out Mute page
This page enables you to set Mute groups (U–X) for Bus Outs (1–8), Aux Outs (1–8) and
Stereo Out.
• In Fader page
• In Mute page

Yamaha 01V96 Specifications

General

Channels	40
Mic Preamps	16
Bit Depth	24-bit
MIDI	Yes
EQ Bands	4-band Parametric
Aux Sends	8
A/D-D/A Conversion	24-bit
Effects Processors	4
Power Supply	Internal
Type	Digital
Sample Rate	44.1 kHz, 48 kHz
Effects	Yes
USB	No
Weight	33 lbs
Inputs - Other	8 digital
Outputs - Digital	AES/EBU, S/PDIF
Computer Connectivity	No
Sampling Rate	44.1 kHz, 48 kHz
Internal Processing	32-bit
Dynamic Processing	Gate, Compressor, Limiter
Digital I/O	AES/EBU, S/PDIF
Analog I/O	XLR, TRS
Outputs - Main	2
