1.13 o: Keypad-Related Settings
100 YASKAWA TOEPYAIGA5002A GA500 DRIVE PROGRAMMING
No.
(Hex.)
Name Description
Default
(Range)
o1-45
(11C5)
RUN
3rd Monitor Area Selection
Sets the horizontal axis value used to display the monitor set in o1-26 [Custom Monitor 3] as a bar
graph. This parameter is only available with an LCD keypad.
0 : +/- Area ( - o1-46 ～ o1-46 )
1 : + Area ( 0 ~ o1-46 )
0
(0 - 1)
o1-46
(11C6)
RUN
3rd Monitor Area Setting
Sets the horizontal axis value used to display the monitor set in o1-26 [Custom Monitor 3] as a bar
graph. This parameter is only available with an LCD keypad.
100.0%
(0.0 - 100.0%)
o1-47
(11C7)
RUN
Trend Plot 1 Scale Minimum
Value
Sets the horizontal axis minimum value used to display the monitor set in o1-24 [Custom Monitor 1]
as a trend plot. This parameter is only available with an LCD keypad.
-100.0%
(-300.0 - +299.9%)
o1-48
(11C8)
RUN
Trend Plot 1 Scale
Maximum Value
Sets the maximum value for the vertical axis used to display the monitor that was set in o1-24
[Custom Monitor 1] as a trend plot. This parameter is only available with an LCD keypad.
100.0%
(-299.9 - +300.0%)
o1-49
(11C9)
RUN
Trend Plot 2 Scale Minimum
Value
Sets the horizontal axis minimum value used to display the monitor set in o1-25 [Custom Monitor 2]
as a trend plot. This parameter is only available with an LCD keypad.
-100.0%
(-300.0 - +299.9%)
o1-50
(11CA)
RUN
Trend Plot 2 Scale
Maximum Value
Sets the maximum value for the vertical axis used to display the monitor that was set in o1-25
[Custom Monitor 2] as a trend plot. This parameter is only available with an LCD keypad.
100.0%
(-299.9 - +300.0%)
o1-51
(11CB)
RUN
Trend Plot Time Scale
Setting
Sets the time scale (horizontal axis) to display the trend plot. When you change this setting, the drive
automatically adjusts the data sampling time. This parameter is only available with an LCD keypad.
300 s
(1 - 3600 s)
o1-55
(11EE)
RUN
Analog Gauge Area
Selection
Sets the range used to display the monitor set in o1-24 [Custom Monitor 1] as an analog gauge. This
parameter is only available with an LCD keypad.
0 : +/- Area ( - o1-56 ～ o1-56 )
1 : + Area ( 0 ~ o1-56 )
1
( 0, 1 )
o1-56
(11EF)
RUN
Analog Gauge Area Setting
Sets the value used to display the monitor set in o1-24 [Custom Monitor 1] as an analog meter. This
parameter is only available with an LCD keypad.
100.0%
(0.0 - 100.0%)
o1-58
(3125)
Motor Power Unit Selection
Sets the setting unit for parameters that set the motor rated power.
0 : kW
1 : HP
1
(0, 1)
◆ o2: Keypad Operation
No.
(Hex.)
Name Description
Default
(Range)
o2-01
(0505)
LO/RE Key Function
Selection
Sets the function that lets you use to switch between LOCAL and REMOTE Modes.
0 : Disabled
1 : Enabled
1
(0, 1)
o2-02
(0506)
STOP Key Function
Selection
Sets the function to use on the keypad to stop the drive when the Run command source for
the drive is REMOTE (external) and not assigned to the keypad.
0 : Disabled
1 : Enabled
1
(0, 1)
o2-03
(0507)
User Parameter Default
Value
Sets the function to keep the settings of changed parameters as user parameter defaults to use during
initialization.
0 : No change
1 : Set defaults
2 : Clear all
0
(0 - 2)
o2-04
(0508)
Drive Model (KVA)
Selection
Sets the Drive Model code. Set this parameter after replacing the control board.
Determined by the drive
(-)
