YASKAWA GA500 GA50U Series User Manual

Parameter Details
2
2.8 H: Terminal Function Selection
YASKAWA TOEPYAIGA5002A GA500 DRIVE PROGRAMMING 309
ON : Normal operation
OFF : Short Circuit Braking is enabled.
■ 7E: Reverse Rotation Identifier
Setting Value Function Description
7E Reverse Rotation Identifier
Sets the motor rotation direction when you use Simple Closed Loop V/f Control method.
ON : Reverse run
The drive knows that the motor is rotating in the reverse direction.
OFF : Forward run
The drive knows that the motor is rotating in the forward direction.
■ 90 to 96: DWEZ Digital Inputs 1 to 7
Setting Value Function Description
90 - 96 DWEZ Digital Inputs 1 to 7
Sets digital inputs used with DriveWorksEZ. Refer to the DriveWorksEZ online manual for more information.
Note:
You cannot set values 90 to 96 for inverse output.
■ 9F: DWEZ Disable
Setting Value Function Description
9F DWEZ Disable
Sets operation of the DriveWorksEZ program saved in the drive.
Note:
Set A1-07 = 2 [DriveWorksEZ Function Selection = Enabled/Disabled wDigital Input] to use this function.
ON : Disabled
OFF : Enabled
■ 101 to 19F: Inverse Input of 1 to 9F
Setting Value Function Description
101 to 19F Inverse Input of 1 to 9F Sets the function of the selected MFDI to operate inversely. To select the function, enter “1xx”, where the “xx” is the function setting
value.
For example, to use the inverse input of E [ASR Integral Reset], set H1-xx = 10E.
Note:
You cannot use inverse input for all functions. Refer to Table 2.46 for more information.
◆ H2: Digital Outputs
H2 parameters set the MFDO terminal functions.
■ H2-01 to H2-03 Terminal MA/MB-MC, P1-C1, P2-C2 Function Selection
The drive has four MFDO terminals. Table 2.52 shows the default function settings for the terminals.
Table 2.52 MFDO Terminals Default Function Settings
No. Name Default Function
H2-01
Term MA/MB-MC Function Selection
(Contact)
E Fault
H2-02 Term P1-C1 Function Selection 0 During Run
H2-03 Term P2-C2 Function Selection 2 Speed Agree 1
Refer to Table 2.53 to set H2-xx [MFDO Function Select].
V/f
OLV
OLV/PM OLV/PM
AOLV/PM
EZOLV
V/f
OLV
OLV/PM OLV/PM
AOLV/PM
EZOLV
V/f
OLV
OLV/PM OLV/PM
AOLV/PM
EZOLV
