2.10 n: Special Adjustment
YASKAWA TOEPYAIGA5002A GA500 DRIVE PROGRAMMING 415
■ n7-10: Pull-in Current Switching Speed
No.
(Hex.)
Name Description
Default
(Range)
n7-10
(311A)
Expert
Pull-in Current Switching
Speed
Sets the speed range to operate with the pull-in current command. Drive rated frequency = 100%
value. If there is a large quantity of oscillation when you operate in the low speed range, increase the
setting value.
10.0%
(0.0 - 100.0%)
Note:
• When the drive accelerates, it enables these settings:
–Motor speed ≤ n7-10 + n7-11 [Drv Mode Switch Hysteresis Band]: n8-51 [Pull-in Current @ Acceleration]
–Motor speed > n7-10 + n7-11: b8-01 [Energy Saving Control Selection]
• When the drive decelerates, it enables these settings:
–Motor speed ≤ n7-10: n8-51 [Pull-in Current @ Acceleration]
–Motor speed > n7-10: b8-01 [Energy Saving Control Selection]
• If there is a large quantity of oscillation when you operate in the low speed range, increase the setting value.
• When it is most important to save energy in the low speed range, decrease the setting value.
■ n7-17: Resistance TemperatureCorrection
No.
(Hex.)
Name Description
Default
(Range)
n7-17
(3122)
Resistance
TemperatureCorrection
Sets the function to adjust for changes in the motor resistance value caused by changes in the
temperature.
1
(0 to 2)
0 : Invalid
1 : Valid (Only 1 time)
2 : Valid (Every time)
Note:
• For settings 1 and 2, the adjustment time can cause a delay before startup.
• For settings 1 and 2, the drive can set the line-to-line resistance value of E9-10 [Motor Line-to-Line Resistance].
• When the temperature will change at startup, use setting 2.
• To decrease the startup time, set this parameter to 0, then do line-to-line resistance tuning.
• If you will start from coasting, set this parameter to 0, then do line-to-line resistance tuning.
■ n7-19: Flux Error Compensation Gain
No.
(Hex.)
Name Description
Default
(Range)
n7-19
(3128)
Expert
Flux Error Compensation
Gain
Sets the gain for magnetic flux compensation. Usually it is not necessary to change this setting.
5000%
(0 - 50000%)
◆ n8: PM Motor Control Tuning
n8 parameters are used to make adjustments when controlling PM motors.
■ n8-01: Pole Position Detection Current
No.
(Hex.)
Name Description
Default
(Range)
n8-01
(0540)
Pole Position Detection
Current
Sets the Initial Rotor Position Estimated Current as a percentage where E5-03 [PM Motor Rated
Current (FLA)] = 100%. Usually it is not necessary to change this setting.
50%
(0 - 100%)
The drive uses the Initial Rotor Position Estimated Current to detect the initial position of rotors.
Use the "Si" value on the motor nameplate, if available.
Note:
When A1-02 = 7 [CLV/PM], this parameter takes effect only in Expert Mode.
