3.5 Auto-Tuning
474 YASKAWA TOEPYAIGA5002A GA500 DRIVE PROGRAMMING
Table 3.8 Input Data for PM Motor Auto-Tuning
Input Data Parameter Unit
Auto-Tuning Mode
(T2-01 Setting)
Manual Entry w/ Motor Data Sheet
(0)
PM Stationary
Auto-Tuning
(1)
PM Stationary Auto-
Tuning for Stator
Resistance
(2)
Control Method Selection A1-02 - 5, 6 5 6 5 6 5, 6
PM Motor Code Selection T2-02 -
Motor code of Yaskawa
motor
*1
FFFF
*2
FFFF
*2
- - -
PM Motor Type T2-03 - - - - x x -
PM Motor Rated Power T2-04 kW - x x x x -
PM Motor Rated Voltage T2-05 V - x x x x -
PM Motor Rated Current T2-06 A - x x x x x
PM Motor Base Frequency T2-07 Hz - x - x - -
Number of PM Motor Poles T2-08 - - x x x x -
PM Motor Base Speed T2-09 min
-1
- - x - x -
PM Motor Stator Resistance T2-10 Ω x x x - - -
PM Motor d-Axis Inductance T2-11 mH x x x - - -
PM Motor q-Axis Inductance T2-12 mH x x x - - -
Back-EMF Units Selection T2-13 - x x x - - -
Back-EMF Voltage Constant
(Ke)
T2-14
*3
x x x - - -
Pull-In Current Level T2-15 % - - - x x -
*1 Set the motor code for a Yaskawa PM motor.
*2 Set the motor code to FFFF for a PM motor from a different manufacturer.
*3 Changes when the value set in T2-13 changes.
Table 3.9 Input Data for PM Motor Auto-Tuning
Input Data Parameter Unit
Auto-Tuning Mode
(T2-01 Setting)
Rotational (Ld, Lq, R, back-EMF)
(4)
High Frequency Injection
(5)
Control Method Selection A1-02 - 5 6 5, 6
PM Motor Code Selection T2-02 - - - -
PM Motor Type T2-03 - x x -
PM Motor Rated Power T2-04 kW x x -
PM Motor Rated Voltage T2-05 V x x -
PM Motor Rated Current T2-06 A x x -
PM Motor Base Frequency T2-07 Hz x - -
Number of PM Motor Poles T2-08 - x x -
PM Motor Base Speed T2-09 min
-1
- x -
Pull-In Current Level T2-15 % x x -
◆ Auto-Tuning in EZ Open Loop Vector Control Method
This section gives information about the Auto-Tuning mode for EZ Open Loop Vector Control. Auto-Tuning will set
the E9-xx parameters.
