Parameter List
1
1.16 T: Motor Tuning
YASKAWA TOEPYAIGA5002A GA500 DRIVE PROGRAMMING 107
No.
(Hex.)
Name Description
Default
(Range)
T1-12
(0BDB)
Test Mode Selection
Sets the function to enable Test Mode after Stationary Auto-Tuning. When you can operate the motor
with a light load attached after Stationary Auto-Tuning is complete, enable this parameter.
Note:
You must first set T1-10 = 0 [Motor Rated Slip Frequency = 0 Hz] to enable this parameter.
0 : No
1 : Yes
0
(0, 1)
T1-13
(0BDC)
No-load voltage
Sets the no-load voltage of the motor. When the no-load voltage at rated speed is available, for
example on the motor test report, set the voltage in this parameter. If the no-load voltage is not
available, do not change this parameter.
Note:
• To get the same qualities as a Yaskawa 1000-series drive or previous series drive, set this
parameter = T1-03 [Motor Rated Voltage].
• The default setting is different for different models.
–B001 - B006, 2001 - 2008, 4001 - 4004: T1-03 × 0.85
–B010 - B018, 2010 - 2082, 4005 - 4060: T1-03 × 0.90
T1-03 × 0.9
(200 V Class: 0.0 - 255.0 V,
400 V Class: 0.0 - 510.0 V)
◆ T2: PM Motor Auto-Tuning
No.
(Hex.)
Name Description
Default
(Range)
T2-01
(0750)
PM Auto-Tuning Selection
Sets the type of Auto-Tuning for PM motors.
0 : Manual Entry w/ Motor Data Sheet
1 : Stationary (Ld, Lq, R)
2 : Stationary (R Only)
4 : Rotational (Ld, Lq, R, back-EMF)
5 : High Frequency Injection
0
(Determined by A1-02)
T2-02
(0751)
PM Motor Code Selection
If the drive is operating an SMRD, SMRA, or SSR1 series Yaskawa PM motor, enter the PM motor
code in to align with the rotation speed and motor output.
FFFF
(0000 - FFFF)
T2-03
(0752)
PM Motor Type
Sets the type of PM motor the drive will operate.
0 : IPM motor
1 : SPM motor
1
(0, 1)
T2-04
(0730)
PM Motor Rated Power
Uses the units set in o1-58 [Motor Power Unit Selection] to set the PM motor rated output power.
Determined by o2-04, C6-01
(0.00 - 650.00 HP)
T2-05
(0732)
PM Motor Rated Voltage
Sets the rated voltage (V) of the motor.
200 V Class: 230.0 V,
400 V Class: 460.0 V
(200 V Class: 0.0 - 255.0 V,
400 V Class: 0.0 - 510.0 V)
T2-06
(0733)
PM Motor Rated Current
Sets the rated current (A) of the motor.
Determined by o2-04
(10% to 200% of the drive
rated current)
T2-07
(0753)
PM Motor Base Frequency
Sets the base frequency (Hz) of the motor.
60.0 Hz
(0.0 - 590.0 Hz)
T2-08
(0734)
Number of PM Motor Poles
Sets the number of motor poles.
4
(2 - 120)
T2-09
(0731)
PM Motor Base Speed
Sets the motor base speed (min
-1
(r/min)).
1750 min
-1
(r/min)
(0 - 34500 min
-1
(r/min))
T2-10
(0754)
PM Motor Stator Resistance
Sets the stator resistance for each motor phase.
Note:
This parameter does not set line-to-line resistance.
Determined by T2-02
(0.000 - 65.000 Ω)
T2-11
(0735)
PM Motor d-Axis
Inductance
Sets the d-axis inductance of the motor on a per phase basis.
Determined by T2-02
(0.00 - 600.00 mH)
T2-12
(0736)
PM Motor q-Axis
Inductance
Sets the q-Axis inductance of the motor on a per phase basis.
Determined by T2-02
(0.00 - 600.00 mH)
