Parameter List
1
1.17 U: Monitors
YASKAWA TOEPYAIGA5002A GA500 DRIVE PROGRAMMING 121
No.
(Hex.)
Name Description MFAO Signal Level
U6-98
(07F8)
First Fault
Shows the contents of the most recent communication options fault (DeviceNet, Modbus TCP/IP,
EtherNet/IP).
No signal output available
U6-99
(07F9)
Current Fault
Shows the contents of current fault from communication options (DeviceNet, Modbus TCP/IP,
EtherNet/IP).
No signal output available
◆ U8: DriveWorksEZ Monitors
No.
(Hex.)
Name Description MFAO Signal Level
U8-01
(1950)
DWEZ Monitor 1
Shows DWEZ Monitor 1. (Display range: 0.00% to 999.99%)
Unit: 0.01%
10 V = 100%
U8-02
(1951)
DWEZ Monitor 2
Shows DWEZ Monitor 2. (Display range: 0.00% to 999.99%)
Unit: 0.01%
10 V = 100%
U8-03
(1952)
DWEZ Monitor 3
Shows DWEZ Monitor 3. (Display range: 0.00% to 999.99%)
Unit: 0.01%
10 V = 100%
U8-04
(1953)
DWEZ Monitor 4
Shows DWEZ Monitor 4. (Display range: 0.00% to 999.99%)
Unit: 0.01%
10 V = 100%
U8-05
(1954)
DWEZ Monitor 5
Shows DWEZ Monitor 5. (Display range: 0.00% to 999.99%)
Unit: 0.01%
10 V = 100%
U8-06
(1955)
DWEZ Monitor 6
Shows DWEZ Monitor 6. (Display range: 0.00% to 999.99%)
Unit: 0.01%
10 V = 100%
U8-07
(1956)
DWEZ Monitor 7
Shows DWEZ Monitor 7. (Display range: -999.9% to +999.99%)
Unit: 0.01%
10 V = 100%
U8-08
(1957)
DWEZ Monitor 8
Shows DWEZ Monitor 8. (Display range: -999.9% to +999.99%)
Unit: 0.01%
10 V = 100%
U8-09
(1958)
DWEZ Monitor 9
Shows DWEZ Monitor 9. (Display range: -999.9% to +999.99%)
Unit: 0.01%
10 V = 100%
U8-10
(1959)
DWEZ Monitor 10
Shows DWEZ Monitor 10.
No signal output available
U8-11
(195A)
DWEZ Version 1
Shows the Upper three digits of the user ID. When you click the setting button on the title bar of the
PC tool to open the setting screen, you can confirm the user ID with the primary user ID display.
No signal output available
U8-12
(195B)
DWEZ Version 2
Shows the lower five digits of the user ID. When you click the setting button on the title bar of the
PC tool to open the setting screen, you can confirm the user ID with the primary user ID display.
No signal output available
U8-13
(195C)
DWEZ Version 3
Shows the software ID.
No signal output available
U8-18
(1961)
DWEZ Platform Ver
Shows the DriveWorksEZ platform version.
No signal output available
U8-21
(1964)
DWEZ Monitor 21
Shows DWEZ Monitor 21. (Display range: -999.9% to +999.99%)
Unit: 0.01%
10 V = 100%
U8-22
(1965)
DWEZ Monitor 22
Shows DWEZ Monitor 22.
Unit: The number of decimal points shown is set with Q2-21.
10 V = 100%
