YASKAWA GA500 GA50U Series User Manual

2.8 H: Terminal Function Selection
318 YASKAWA TOEPYAIGA5002A GA500 DRIVE PROGRAMMING
■ H2-63: Terminal P1 Secondary Function
No.
(Hex.)
Name Description
Default
(Range)
H2-63
(1B49)
Expert
Terminal P1 Secondary
Function
Sets the second function for terminal P1-C1. Outputs the logical calculation results of the terminals
set to functions by H2-02 [Term P1 Function Selection].
F
(0 - FF)
■ H2-64: Terminal P1 Logical Operation
No.
(Hex.)
Name Description
Default
(Range)
H2-64
(1B4A)
Expert
Terminal P1 Logical
Operation
Sets the logical operation for the functions set in H2-02 [Term P1 Function Selection] and H2-63
[Terminal P1 Secondary Function].
0
(0 - 8)
Note:
Refer to Output of Logical Operation Results of MFDO on page 311 for more information about the relation between parameter settings and
logical operations.
■ H2-65: Terminal P1 Minimum ON Time
No.
(Hex.)
Name Description
Default
(Range)
H2-65
(1B4B)
Expert
Terminal P1 Minimum ON
Time
Sets the minimum ON time used to output the logical calculation results from terminal P1-C1.
0.1 s
(0.0 - 25.0 s)
■ H2-66: Terminal P2 Secondary Function
No.
(Hex.)
Name Description
Default
(Range)
H2-66
(1B4C)
Expert
Terminal P2 Secondary
Function
Sets the second function for terminal P2-C2. Outputs the logical calculation results of the terminals
assigned to functions by H2-03 [Term P2 Function Selection].
F
(0 - FF)
■ H2-67: Terminal P2 Logical Operation
No.
(Hex.)
Name Description
Default
(Range)
H2-67
(1B4D)
Expert
Terminal P2 Logical
Operation
Sets the logical operation for the functions set in H2-03 [Term P2 Function Selection] and H2-66
[Terminal P2 Secondary Function].
0
(0 - 8)
Note:
Refer to Output of Logical Operation Results of MFDO on page 311 for more information about the relation between parameter settings and
logical operations.
■ H2-68: Terminal P2 Minimum ON Time
No.
(Hex.)
Name Description
Default
(Range)
H2-68
(1B4E)
Expert
Terminal P2 Minimum ON
Time
Sets the minimum ON time used to output the logical calculation results from terminal P2-C2.
0.1 s
(0.0 - 25.0 s)
◆ MFDO Setting Values
Selects the function configured to MFDO.
V/f
OLV
OLV/PM OLV/PM
AOLV/PM
EZOLV
V/f
OLV
OLV/PM OLV/PM
AOLV/PM
EZOLV
V/f
OLV
OLV/PM OLV/PM
AOLV/PM
EZOLV
V/f
OLV
OLV/PM OLV/PM
AOLV/PM
EZOLV
V/f
OLV
OLV/PM OLV/PM
AOLV/PM
EZOLV
V/f
OLV
OLV/PM OLV/PM
AOLV/PM
EZOLV
