ZyXEL Communications LTE5388-M804 User Manual

Chapter 8 Home Networking
LTE Series User’s Guide
138
8.4 UPnP
Universal Plug and Play (UPnP) is an open networking standard that uses TCP/IP for simple peer-to-peer
network connectivity between networking devices or software applications which have UPnP enabled.
A UPnP device can dynamically join a network, obtain an IP address, advertise its services, and learn
about other devices on the network. A device can also leave a network automatically when it is no
longer in use.
See Section 8.6 on page 140 for more information on UPnP.
Use the following screen to configure the UPnP settings on your Zyxel Device. Click Network Setting >
Home Networking > UPnP to display the screen shown next.
Figure 93 Network Setting > Home Networking > UPnP
The following table describes the labels in this screen.
OK Click OK to save your changes.
Cancel Click Cancel to exit this screen without saving.
Table 43 Static DHCP: Configuration
LABEL DESCRIPTION
Table 44 Network Settings > Home Networking > UPnP
LABEL DESCRIPTION
UPnP State
UPnP Select Enable to activate UPnP. Be aware that anyone could use a UPnP application to open
the Web Configurator's login screen without entering the Zyxel Device's IP address (although
you must still enter the password to access the Web Configurator).
UPnP NAT-T State

ZyXEL Communications LTE5388-M804 Specifications

General

DSL WAN	No
Ethernet WAN	Yes
WAN connection type	RJ-45
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1733 Mbit/s
WLAN data transfer rate (first band)	300 Mbit/s
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
4G standard	LTE-TDD & LTE-FDD
3G standards	HSPA+, HSUPA, WCDMA
UMTS bands supported	850, 900, 1800, 2100 MHz
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	2
MAC address table	64 entries
Security algorithms	WPA, WPA2
Supported network protocols	IPv4/IPv6
Product type	Tabletop router
Product color	Grey, White
LED indicators	LTE, Power, USB, WLAN
Power source type	DC
Power consumption (typical)	24 W
Certification	CE, WEEE, RoHS, HSF
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Cables included	LAN (RJ-45), Phone (RJ-11)
Package type	Box
Package depth	170 mm
Package width	247 mm
Package height	120 mm
Package weight	1600 g
Harmonized System (HS) code	85176990

Weight and Dimensions

Width	100 mm
Height	205 mm
Weight	599 g
