ZyXEL Communications LTE5388-M804 User Manual

Chapter 9 Routing
LTE Series User’s Guide
155
Figure 114 Network Setting > Routing > Static Route
The following table describes the labels in this screen.
9.2.1 Add/Edit Static Route
Click Add New Static Route in the Static Route screen, the following screen appears. Configure the
required information for a static route.
Note: The Gateway IP Address must be within the range of the selected interface in Use
Interface.
Table 45 Network Setting > Routing > Static Route
LABEL DESCRIPTION
Add New Static
Route
Click this to set up a new static route on the Zyxel Device.
# This is the number of an individual static route.
Status This field indicates whether the rule is active (yellow bulb) or not (gray bulb).
Name This is the name of the static route.
Destination IP This parameter specifies the IP network address of the final destination. Routing is always based
on network number.
Subnet Mask/
Prefix Length
This parameter specifies the IP network subnet mask of the final destination.
Gateway This is the IP address of the gateway. The gateway is a router or switch on the same network
segment as the Zyxel Device's LAN or WAN port. The gateway helps forward packets to their
destinations.
Interface This is the WAN interface through which the traffic is routed.
Modify Click the Edit icon to go to the screen where you can set up a static route on the Zyxel Device.
Click the Delete icon to remove a static route from the Zyxel Device.

ZyXEL Communications LTE5388-M804 Specifications

General

DSL WAN	No
Ethernet WAN	Yes
WAN connection type	RJ-45
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1733 Mbit/s
WLAN data transfer rate (first band)	300 Mbit/s
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
4G standard	LTE-TDD & LTE-FDD
3G standards	HSPA+, HSUPA, WCDMA
UMTS bands supported	850, 900, 1800, 2100 MHz
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	2
MAC address table	64 entries
Security algorithms	WPA, WPA2
Supported network protocols	IPv4/IPv6
Product type	Tabletop router
Product color	Grey, White
LED indicators	LTE, Power, USB, WLAN
Power source type	DC
Power consumption (typical)	24 W
Certification	CE, WEEE, RoHS, HSF
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Cables included	LAN (RJ-45), Phone (RJ-11)
Package type	Box
Package depth	170 mm
Package width	247 mm
Package height	120 mm
Package weight	1600 g
Harmonized System (HS) code	85176990

Weight and Dimensions

Width	100 mm
Height	205 mm
Weight	599 g
