ZyXEL Communications LTE5388-M804 User Manual

Chapter 27 Remote Management
LTE Series User’s Guide
250
Figure 180 Maintenance > Remote Management > MGMT Services for IP Passthrough
The following table describes the fields in this screen.
27.4 Trust Domain
Use this screen to view a list of public IP addresses which are allowed to access the Zyxel Device through
the services configured in the Maintenance > Remote Management > MGMT Services screen. Click
Maintenance > Remote Management > Trust Domain to open the following screen.
Note: Enter the IP address of the management station permitted to access the local
management services. If specific services from the trusted hosts are allowed access but
the trust domain list is empty, all public IP addresses can access the Zyxel Device from
the WAN using the specified services.
Figure 181 Maintenance > Remote Management > Trust Domain
Table 105 Maintenance > Remote Management > MGMT Services for IP Passthrough
LABEL DESCRIPTION
Service This is the service you may use to access the Zyxel Device.
WAN Select the Enable check box for the corresponding services that you want to allow access to the
Zyxel Device from all WAN connections.
Port You may change the server port number for a service if needed, however you must use the
same port number in order to use that service for remote management.
Apply Click Apply to save your changes back to the Zyxel Device.
Cancel Click Cancel to restore your previously saved settings.

ZyXEL Communications LTE5388-M804 Specifications

General

DSL WAN	No
Ethernet WAN	Yes
WAN connection type	RJ-45
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1733 Mbit/s
WLAN data transfer rate (first band)	300 Mbit/s
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
4G standard	LTE-TDD & LTE-FDD
3G standards	HSPA+, HSUPA, WCDMA
UMTS bands supported	850, 900, 1800, 2100 MHz
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	2
MAC address table	64 entries
Security algorithms	WPA, WPA2
Supported network protocols	IPv4/IPv6
Product type	Tabletop router
Product color	Grey, White
LED indicators	LTE, Power, USB, WLAN
Power source type	DC
Power consumption (typical)	24 W
Certification	CE, WEEE, RoHS, HSF
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Cables included	LAN (RJ-45), Phone (RJ-11)
Package type	Box
Package depth	170 mm
Package width	247 mm
Package height	120 mm
Package weight	1600 g
Harmonized System (HS) code	85176990

Weight and Dimensions

Width	100 mm
Height	205 mm
Weight	599 g
