LTE Series User’s Guide
269
CHAPTER 34
Diagnostic
34.1 Diagnostic Overview
The Diagnostic screens display information to help you identify problems with the Zyxel Device.
34.2 Ping/TraceRoute/Nslookup Test
Use this screen to ping, traceroute, or nslookup for troubleshooting. Ping and traceroute are used to test
whether a particular host is reachable. After entering an IP address and clicking one of the buttons to
start a test, the results will be shown in the Ping/Traceroute Test area. Use nslookup to find the IP address
for a host name and vice versa. Click Maintenance > Diagnostic to open the Ping/TraceRoute/Nslookup
screen shown next.
Figure 195 Maintenance > Diagnostic > Ping/Trace Route/Nslookup
The following table describes the fields in this screen.
Table 117 Maintenance > Diagnostic
LABEL DESCRIPTION
Ping/
TraceRoute
Test
The result of tests is shown here in the info area.
TCP/IP

ZyXEL Communications LTE5388-M804 Specifications

General

DSL WAN	No
Ethernet WAN	Yes
WAN connection type	RJ-45
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1733 Mbit/s
WLAN data transfer rate (first band)	300 Mbit/s
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
4G standard	LTE-TDD & LTE-FDD
3G standards	HSPA+, HSUPA, WCDMA
UMTS bands supported	850, 900, 1800, 2100 MHz
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	2
MAC address table	64 entries
Security algorithms	WPA, WPA2
Supported network protocols	IPv4/IPv6
Product type	Tabletop router
Product color	Grey, White
LED indicators	LTE, Power, USB, WLAN
Power source type	DC
Power consumption (typical)	24 W
Certification	CE, WEEE, RoHS, HSF
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Cables included	LAN (RJ-45), Phone (RJ-11)
Package type	Box
Package depth	170 mm
Package width	247 mm
Package height	120 mm
Package weight	1600 g
Harmonized System (HS) code	85176990

Weight and Dimensions

Width	100 mm
Height	205 mm
Weight	599 g
