ZyXEL Communications LTE5388-M804 User Manual

Chapter 17 Voice
LTE Series User’s Guide
215
17.3.3 SIP Service Provider
Use this screen to view the SIP service provider information on the Zyxel Device. A SIP provider offers
Internet call services using VoIP technology. You may need to consult your SIP service provider for the
following settings. To access this screen, click Voice > SIP > SIP Service Provider.
Figure 160 Voice > SIP > SIP Service Provider
The following table describes the labels in this screen.
17.3.4 Provider Entry Edit
Use this screen to configure the SIP server information, the numbers for certain phone functions
and dialing plan for a SIP service provider. Click Voice > SIP > SIP Service Provider and then click the
Modify icon next to a profile of SIP service provider settings to open the following screen.
Table 85 Voice > SIP > SIP Service Provider
LABEL DESCRIPTION
# This is the index number of the entry.
SIP Service Provider Name This shows the name of the SIP service provider.
SIP Proxy Server Address This shows the IP address or domain name of the SIP server.
Register Server Address This shows the IP address or domain name of the SIP register server.
SIP Service Domain Enter the SIP service domain name. In the full SIP URI, this is the part after the
@symbol. You can use up to 127 printable ASCII Extended set characters.
Modify Click the Modify icon to configure the profile of SIP service provider settings.

ZyXEL Communications LTE5388-M804 Specifications

General

DSL WAN	No
Ethernet WAN	Yes
WAN connection type	RJ-45
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1733 Mbit/s
WLAN data transfer rate (first band)	300 Mbit/s
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
4G standard	LTE-TDD & LTE-FDD
3G standards	HSPA+, HSUPA, WCDMA
UMTS bands supported	850, 900, 1800, 2100 MHz
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	2
MAC address table	64 entries
Security algorithms	WPA, WPA2
Supported network protocols	IPv4/IPv6
Product type	Tabletop router
Product color	Grey, White
LED indicators	LTE, Power, USB, WLAN
Power source type	DC
Power consumption (typical)	24 W
Certification	CE, WEEE, RoHS, HSF
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Cables included	LAN (RJ-45), Phone (RJ-11)
Package type	Box
Package depth	170 mm
Package width	247 mm
Package height	120 mm
Package weight	1600 g
Harmonized System (HS) code	85176990

Weight and Dimensions

Width	100 mm
Height	205 mm
Weight	599 g
