Chapter 17 Voice
LTE Series User’s Guide
221
Figure 164 Voice > Call History
The following table describes the labels in this screen.
17.6.2 Call Summary Screen
The Zyxel Device logs calls to or from your SIP addresses. This screen allows you to view the summary of
received, dialed and missed calls. To access this screen, click Voice > Call History > Call Summary.
Figure 165 Voice > Call History > Call Summary
Table 89 Voice > Call History
LABEL DESCRIPTION
Classify Select the type of the calls. The call types are: Incoming, Outgoing and Missed.
Clear List Click this button to remove all entries from the call history list.
Refresh Click this button to renew the call history list.
Export Click Export to download a call history list.
Type This displays the type of the calls.
Date This displays the date when the calls were made.
Name This displays the SIP account you called.
Number This displays the SIP number you called.
Phone Device This field displays the name of a phone port on the Zyxel Device.
Outgoing Number This displays how many calls originated from you that day.
Duration This displays how long the current call has lasted.
Modify Click the Modify icon to make changes to the call history.

ZyXEL Communications LTE5388-M804 Specifications

General

DSL WAN	No
Ethernet WAN	Yes
WAN connection type	RJ-45
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1733 Mbit/s
WLAN data transfer rate (first band)	300 Mbit/s
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
4G standard	LTE-TDD & LTE-FDD
3G standards	HSPA+, HSUPA, WCDMA
UMTS bands supported	850, 900, 1800, 2100 MHz
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	2
MAC address table	64 entries
Security algorithms	WPA, WPA2
Supported network protocols	IPv4/IPv6
Product type	Tabletop router
Product color	Grey, White
LED indicators	LTE, Power, USB, WLAN
Power source type	DC
Power consumption (typical)	24 W
Certification	CE, WEEE, RoHS, HSF
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Cables included	LAN (RJ-45), Phone (RJ-11)
Package type	Box
Package depth	170 mm
Package width	247 mm
Package height	120 mm
Package weight	1600 g
Harmonized System (HS) code	85176990

Weight and Dimensions

Width	100 mm
Height	205 mm
Weight	599 g
