ZyXEL Communications LTE5388-M804 User Manual

Chapter 13 Firewall
LTE Series User’s Guide
187
13.4 Protocol (Customized Services)
You can configure customized services and port numbers in the Protocol screen. Each set of protocol
rules listed in the table are reusable objects to be used in conjunction with ACL rules in the Access
Control screen. For a comprehensive list of port numbers and services, visit the IANA (Internet Assigned
Number Authority) website. Click Security > Firewall > Protocol to display the following screen.
Note: Removing a protocol rule will also remove associated ACL rules.
Figure 140 Security > Firewall > Protocol
The following table describes the labels in this screen.
13.4.1 Add Customized Service
Add a customized rule or edit an existing rule by specifying the protocol and the port numbers. Click
Add New Protocol Entry in the Protocol screen to display the following screen.
Table 67 Security > Firewall > Protocol
LABEL DESCRIPTION
Add New
Protocol
Entry
Click this to configure a customized service.
Name This is the name of your customized service.
Description This is a description of your customized service.
Ports/
Protocol
Number
This shows the port number or range and the IP protocol (TCP or UDP) that defines your customized
service.
Modify Click this to edit a customized service.

ZyXEL Communications LTE5388-M804 Specifications

General

DSL WAN	No
Ethernet WAN	Yes
WAN connection type	RJ-45
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1733 Mbit/s
WLAN data transfer rate (first band)	300 Mbit/s
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
4G standard	LTE-TDD & LTE-FDD
3G standards	HSPA+, HSUPA, WCDMA
UMTS bands supported	850, 900, 1800, 2100 MHz
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	2
MAC address table	64 entries
Security algorithms	WPA, WPA2
Supported network protocols	IPv4/IPv6
Product type	Tabletop router
Product color	Grey, White
LED indicators	LTE, Power, USB, WLAN
Power source type	DC
Power consumption (typical)	24 W
Certification	CE, WEEE, RoHS, HSF
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Cables included	LAN (RJ-45), Phone (RJ-11)
Package type	Box
Package depth	170 mm
Package width	247 mm
Package height	120 mm
Package weight	1600 g
Harmonized System (HS) code	85176990

Weight and Dimensions

Width	100 mm
Height	205 mm
Weight	599 g
