3 Maintenance
3.3.14. Inspection, signal lamp
1733HAC023082-001 Revision: E
© Copyright 2004-2008 ABB. All rights reserved.
3.3.14. Inspection, signal lamp
Location of signal lamp
The signal lamp is located as shown in the figure below. Note that the position can differ
depending on how the customer harness for axis 4-6 is mounted. See assembly drawing on
the current harness for alternative positioning.
xx0200000240
A Signal lamp
B Clamp
C Position for cable gland
D Warning label on motor cover
E Warning sign on motor cover
Continues on next page
