ABB IRB 6600 - 225/2.55 type B User Manual

9 Spare part / part list
9.3.2. Rebuilding parts
4493HAC023082-001 Revision: E
© Copyright 2004-2008 ABB. All rights reserved.
9.3.2. Rebuilding parts
Overview
The robot has some rebuilding parts that differ from eachother, depending on the robot
version. This section is a general overview of which parts belong to which versions.
The following section, Part list on page 448 also gives further details of the parts specified
below, according to the item numbers given.
Rebuilding parts
Art. no. Part IRB 6600- IRB 6650- IRB 6650S-
Item no
and type
175/
2.55
225/
2.55
175/
2.8
200/
2.75
125/
3.2
200/
3.0
125/
3.5
90/
3.9
3HAC15866-1 Frame / typeA X X X X X 101.2.1
3HAC020136-004 Frame / typeB X X X X 101.2.1
3HAC 10141-1 Lower arm /typeA X X X 105
3HAC 13940-1 Lower arm / typeA X X 105
3HAC020671-003 Lower arm / typeB X X 105
3HAC020129-003 Lower arm / type B X X 105
3HAC026574-001 Lower arm / type B
(Foundry Prime)
X X 105
3HAC020505-003 Lower arm X X X 105
3HAC17212-1 Sealing axis 2/3 / typeA X X X X X 108.201
3HAC020123-001 Sealing axis 2/3 / typeB X X X X X X X 108.201
3HAB3409-84 Screw M16x50 18X 18X 108.202
3HAA1001-186 Washer 7x25x3 18X 18X 108.204
3HAC020958-001 Cable protection / typeA X X X X X 108.235
3HAC021071-001 Cable protection / typeB X X X X X X X 108.235
3HAC16926-1 Lower arm cable protection X X X 108.211
3HAC020507-001 Lower arm cable protection X X X X X 108.211
3HAC14940-1 Harness ax. 1-4 X X X 106
3HAC16331-1 Harness ax.1-4 X X X X 106
3HAC024385-001 Harness ax.1-6 X X X 106
3HAC024386-001 Harness ax.1-6 X X X X X 106
3HAC9760-3 Arm extender 250mm X 111.501
Standard
3HAC15859-2 Arm extender 250mm X 111.501
Standard
and Foundry
3HAC9760-7 Arm extender 450mm X X 2X 111.501
Standard
3HAC15859-3 Arm extender 450mm X X 2X 111.501
Standard
and Foundry
3HAB7700-69 Screw M12x50 12X 12X 12X 24X 111.503
Continues on next page
