ABB IRB 6600 - 225/2.55 type B User Manual

9 Spare part / part list
9.3.15. Material set, balancing device, 3HAC 13265-1
4733HAC023082-001 Revision: E
© Copyright 2004-2008 ABB. All rights reserved.
9.3.15. Material set, balancing device, 3HAC 13265-1
Overview
Item Qty Art. number Description Dimension
110.401 1 3HAC 12441-2 Spherical roller bearing 65 x 120 x 38
110.402 1 3HAC 12481-1 Thrust washer
110.403 1 3HAC 12627-1 Bushing
110.404 1 9ABA 135-31 Retaining ring, shaft 65
110.405 1 3HAC 12480-1 Shaft
110.406 1 3HAC 4836-7 Protection plug 16 x 12.3 x 9 x 7
110.407 4 3HAB 7700-5 Hex socket head cap screw M16 x 70
110.408 2 9ABA 107-56 Parallel pin 10 x 20
110.409 1 3HAC 12548-1 Protection washer T=1
110.410 1 3HAC 12534-1 Shaft, balancing device
110.411 4 3HAA 1001-186 Washer 17 x 25 x 3
110.412 50 ml 3HAA 1001-294 Grease
110.413 2 3HAC 4836-1 Protection plug 20 x 14.6 x 7.5 x 5.5
110.414 1 9ADA 183-490 Hex socket head cap screw M16 x 180
110.415 1 9ADA 312-10 Plain washer 17 x 30 x 3
