3.4.6. Oil change, gearbox, axis 5
Location of gearbox
The axis 5 gearbox is located in the wrist unit as shown in the figure below.
xx0200000232
xx0500002013
- Wrist unit of IRB 6600 and IRB 6650
A Oil plug, filling
B Oil plug, draining
A Wrist unit of IRB 6600ID and IRB 6650ID
B Oil plug, filling
C Oil plug, draining
