ABB IRB 6600 - 225/2.55 type B User Manual

9 Spare part / part list
9.3.13. Material set, manipulator, 3HAC 13263-1
4693HAC023082-001 Revision: E
© Copyright 2004-2008 ABB. All rights reserved.
9.3.13. Material set, manipulator, 3HAC 13263-1
Overview
Item Qty Art. number Description
Dimension /
Note
108.201 1 3HAC 020123-001 Sealing axis 2/3 Axis 2
108.201 1 3HAC 17212-1 Sealing axis 2/3 Axis 3
108.202 18 3HAB 3409-84 Hex socket head cap screw M16 x 50
108.202 33 3HAB 7700-69 Hex socket head cap screw M12 x 50
108.203 3 3HAC 12703-1 Washer, axis 3
108.204 18 3HAA 1001-186 Washer 17 x 25 x 3
108.206 12 3HAB 7700-69 Hex socket head cap screw M12 x 50
108.207 12 3HAA 1001-134 Washer 13 x 19 x 1.5
108.210 1 3HAC 14300-1 Cable protector
108.211 1 3HAC020507-001 Lower arm cable protection
(IRB6650 and IRB 6650ID)
108.211 1 3HAC 16926-1 Lower arm cable protection
(IRB6600 and IRB 6600ID)
108.212 1 3HAC 11771-1 Cable guide, end part
108.213 1 3HAC 13960-1 Connection plate, ax3 t = 4 mm
108.214 2 3HAC 12320-1 Damper, axis 3
108.215 2 3HAC 12991-1 Damper, axis 2
108.216 2 9ADA 624-65 Torx counters. head screw M6 x 60
108.217 2 9ADA 334-7 Spring washer, conical 8.4 x 18 x 2
108.218 2 9ADA 618-57 Torx pan head screw M6 x 20
108.220 2 3HAC 9953-1 Syncplate with vernier T=1.5
108.222 1 3HAC 12719-1 Syncplate with vernier ax3 T=1.5
108.223 2 9ADA 183-48 Hex socket head cap screw M10 x 16
108.224 1 3HAC 12844-1 Cable cover
108.224 1 3HAC026340-003 Cable cover Foundry Prime
108.225 21 9ADA 618-56 Torx pan head screw M6 x 16
108.228 1 3HAC 3261-1 Cover
108.229 1 3HAC 15431-1 Cable protection
108.230 1 3HAC 14880-1 Cable fixing bracket t=3
108.231 1 21520441-1 Washer
108.232 6 3HAC 16721-1 Magnetic plug R 1/2”
108.233 1 2522122-1 Magnetic plug G 1/4"
108.234 3 9ADA 618-56 Torx pan head screw M6 x 16
108.235 1 3HAC 021071-001 Cable protection lower arm
