4 Repair
4.6.3. Replacement of motor, axis 3
3HAC023082-001 Revision: E350
© Copyright 2004-2008 ABB. All rights reserved.
4.6.3. Replacement of motor, axis 3
Location of motor
The motor axis 3 is located on the left hand side of the robot as shown in the figure below.
xx0200000186
xx0600003051
A Motor axis 3
B Cable gland cover, motor axis 3
C Motor attachment holes (4 pcs)
A Cable gland cover, motor axis 3
B Motor attachment holes (4 pcs)
C Motor, axis 3
Continues on next page
