ABB Terra 360 CE User Manual

Parameter Specification
[m] [ft]
Length of the EV charge cable (air-
cooled) for CCS 1, CCS 2 and CHAdeMO
1
4 13
6 20
8 26
Length of the EV charge cable (liquid-
cooled) for CCS 1 and CCS 2
5 16
10.11.2 General dimensions (Terra 180 and 60)
Parameter Specification
[mm] [in]
Width of the cabinet (X-dimension) 1210 48
Depth of the cabinet (Y-dimension, mini-
mum)
565 22
Height of the cabinet (Z-dimension) 2215 87
Maximum opening size of the cable inlet 32 1.3
Diameter of the cable entry hole 12 0.5
Parameter Specification
[m] [ft]
Length of the EV charge cable (air-
cooled) for CCS 1, CCS 2 and CHAdeMO
2
4 13
6 20
8 26
Length of the EV charge cable (liquid-
cooled) for CCS 1 and CCS 2
5 16
10.11.3 Packaged product
The EVSE is mounted on a standard size wooden pallet (Europallet) and protected
to prevent damages during transport.
• A road packaged EVSE is protected with a plastic wrapping.
• A wooden crate packaged EVSE is protected with a plastic wrapping and
enclosed in a box.
Parameter
Specification
[metric] [imperial]
Width 1000 mm 39.37 in
Depth 1250 mm 49.21 in
Heigth 2500 mm 98.43 in
Mass of a road packaged EVSE EVSE weight + 35
kg
EVSE weight + 77 lb
1
Different lengths possible: standard, long and extra long
2
Different lengths possible: standard, long and extra long
Technical data
102 9AKK108467A6398-EN | 002
