ABB Terra 360 CE - EVSE Rating in Heavy Duty Operation

Parameter Specification Example of
power out-
put for Ter-
ra 360-12PM
Ambient temperature Power Out-
put (see
normal duty
rating)
De-rating Peak dura-
tion
[°C] [°F] [%] [%] [min]
[kW]
- 35 … + 20 -31 … + 68 100 - > 30 360 (peak)
+ 21 … + 25 + 69 …+ 77 100 - 15 360 (peak)
+ 26 … + 30 + 78 …+ 86 100 - 10 360 (peak)
+ 31 … + 35 + 87 …+ 96 100 - 6,5 360 (peak)
+ 36 … + 40 + 96 …+ 104 100 - 3,5 360 (peak)
+ 41 … + 45 + 105 …+ 113 92 8 - 331 kW
+ 46 … + 50 + 114 …+ 122 83 17 - 300 kW
+ 51 … + 55 + 123 …+ 131 75 25 - 270 kW
The below table shows the steady state rating of the EVSE.
Parameter
Specification Example of
power out-
put for Ter-
ra 360-12PM
Ambient temperature Power Out-
put (see
normal duty
rating)
De-rating
[°C] [°F] [%] [%]
[kW]
- 35 … + 20 - 31 … + 68 100 360
+ 21 … + 25 + 69 …+ 77 99 1 356
+ 26 … + 30 + 68 …+ 86 97 3 350
+ 31 … + 35 + 87 …+ 96 96 4 346
+ 36 … + 40 + 96 …+ 104 94 6 338
+ 41 … + 45 + 105 …+ 113 92 8 331
+ 46 … + 50 + 114 …+ 122 83 17 300
+ 51 … + 55 + 123 …+ 131 75 25 270
The output power of the EVSE can be limited by the temperature of the charge
connector. This limitation can be caused by the connector model and rating, the EV
socket rating and the ambient conditions.
10.13.3 EVSE rating in heavy duty operation
Heavy duty operation applies for use in public applications with heavy traffic or
commercial/fleet applications.
Technical data
9AKK108467A6398-EN | 002 111
