ABB Terra 360 CE User Manual

Procedure
1. Open the front door. Refer to section 8.1.
2. Connect the parts that follow:
• The wires of the AC input cable and neutral.
• For Terra 360, refer to section 5.7.2
• For Terra 180 and 60, refer to section 5.7.3.
• The PE wire.
• For Terra 360, refer to section 5.7.5
• For Terra 180 and 60, refer to section 5.7.6.
3. If it is necessary, connect the Ethernet cable.
• For Terra 360, refer to section 5.7.7
• For Terra 180, refer to section 5.7.8.
• For Terra 60, refer to section 3.6.
4. Install the protection plate.
5. Close the front door. Refer to section 8.2.
5.7.2 Connect the wires of the AC input cable (Terra 360)
Preliminary requirements
• The front door is open.
• Cable lugs M11
• Fasteners M11
•
Installation engineer
•
• Wire stripper pliers
• Wire cutter
• Crimp plier tool
• Torque socket wrench
Installation
9AKK108467A6398-EN | 002 67
