4. Prepare the cables:
• AC input cable. Refer to section 10.15.
• PE wire. The diameter depends on the length, method of installation and
other factors. Make sure that the PE wire is in accordance with the safety
instructions. Refer to section 2.10.
• Ethernet cable, if no wireless 3G/4G signal is available. Refer to section 10.12.
Contact the manufacturer if you require a specific configuration. Refer to
section 1.11.
Note:
• The cables enter the cabinet from the bottom.
• Take into account the maximum opening of the cable inlet when you
prepare the cables. Refer to section 10.11.2 or 10.11.1.
5. If you use an Ethernet cable, make sure that the internet connection is available
for an approved service engineer and the network operating center of the
manufacturer.
6. Make sure that the cable slack is sufficient to guide the cables in the cabinet.
Refer to section 10.11.11.
7. Prepare the foundation for the cabinet. Refer to section 5.3.
5.2.2 Control the space and airflow around the cabinet
Preliminary requirements
• Installation engineer
Procedure
1. Make sure that the floor space is in accordance with the requirements. Refer to
section 10.11.7.
2. Make sure that the air flow inlet and outlet cannot get blocked. Think of snow or
objects.
5.3 Prepare the foundation
5.3.1 Prepare the foundation - general procedure
Preliminary requirements
• Installation engineer
Procedure
1. Select the correct foundation, based on the surface you install the cabinet on.
2. Embed the cables in the ground with or without a cable duct. Refer to the local
rules.
Installation
58 9AKK108467A6398-EN | 002
